PP-1U-48H · 1U · 48 Port · High Density
SUNPU 1U 48-port high-density keystone patch panel
SUNPU product reference

Connectivity / High-Density Panel

1U 48-Port High-Density Keystone Panel

A 48-port 1U panel direction for space-efficient modular copper patching where jack width, plug access, and cord management are planned together.

1U48 PortHigh Density
Ask about PP-1U-48H on WhatsApp ↗View product familyView Cat6 Patch PanelView Unloaded Keystone Patch Panel

Performance, standards, environmental rating, certification, MOQ, and lead time are confirmed against the exact construction and order requirement.

View SUNPU official product reference ↗

Product overview

Key product considerations

01

Twice the 1U density

Consolidates more ports while preserving a familiar 19-inch rack format.

02

Fit must be proven

Jack body, shield, plug boot, and release-latch access all matter at this density.

03

Management by design

Use slim cords and adjacent horizontal management to reduce congestion.

Model-specific purchase brief

Use the published model as the starting point for the RFQ.

This page identifies the current SUNPU catalogue reference. The final order remains tied to the approved construction, option list, documents, quantity, packaging, and destination requirement.

Published reference
PP-1U-48H
Product category
Connectivity / High-Density Panel
Typical use
High-density data racks · Colocation cabinets · Space-limited telecom rooms

Confirm these order fields

  • Port numbering
  • Label strip
  • Grounding kit
  • Packaging

Specifications

Core product specifications

Loading format
Unloaded keystone panel; modules selected separately
Port count
48 positions in 1U
Published front feature
Shutter and paper-label configuration
Rear cable support
Support bar described in the product reference
Module selection
UTP or STP modules, subject to physical fit and grounding review
Form factor
19-inch, 1U
Capacity
Up to 48 modular positions by panel design
Configuration
Unloaded
Access
Front-service patching
Identification
Numbering and label options

Specification evidence

Specifications to confirm

Published unloaded 1U 48-position high-density keystone panel configuration

SUNPU published product reference ↗

Reviewed 2026-10-26. Only explicitly stated configuration details are used. Performance, certification, plating thickness and tested compatibility require the exact model documents.

  1. 01Panel body depth, mounting-hole drawing and tolerances
  2. 02Matched jack or IDC conductor range for the supplied version
  3. 03Exact metal, finish, thickness, supplied hardware and pack quantities

Configuration options

Available product options

Use these fields to turn a broad product name into an orderable configuration.

  1. 01Port numbering
  2. 02Label strip
  3. 03Grounding kit
  4. 04Packaging

Compatibility checklist

Confirm the complete system

Approve the exact keystone model with the panel

Use slim or suitable boot-profile cords

Check switch and manager layout for access

Typical applications

01

High-density data racks

02

Colocation cabinets

03

Space-limited telecom rooms

RFQ checklist

Information required for quotation

Attach a BOQ, drawing, reference sample, or target datasheet whenever available.
